Grindex Major Inox Stainless Steel Pump
With its impressive allowed pH range, from 2 up to 11, it is hard to find an application that can't be handled by the Inox pumps. The modular design drives service cost down and at the same time offers the flexibility to change from a Normal pressure pump (N), to a High pressure pump (H). All materials in contact with the liquid are made out of AISI 316 stainless steel or better.
Pump type
Electrical submersible Three-phase
Classification
IP 68
Max submersion
20 meters
Cable
20 meters, SUBCAB: 3-phase: 4G2.5mm2
Discharge connection
N : 4" - hose, ISO-G or NPT H : 3" - hose, ISO-G or NPT
Limitations
pH 2-11
Max liquid temp
40°C
| 60 Hz | N | H |
| Discharge connection | 4" | 3" |
| Rated power P2 [kW/hp] | 6.7 / 9 | 6.7 / 9 |
| Max. power consumption P1 [kW] | 7.6 | 7.6 |
| Shaft speed [rpm] | 3455 | 3455 |
| Rated current at 230V | 21 A | 21 A |
| Rated current at 460V | 11 A | 11 A |
| Rated current at 575V | 8.6 A | 8.6 A |
| Solids passage [mm/inch] | 8.5 / 0.35 | 8.5 / 0.35 |
| Height [mm/inch] | 665 / 26¼ | 665 / 26¼ |
| Width [mm/inch] | 333 / 13¼ | 333 / 13¼ |
| Weight [kg/lbs] | 65 / 144 | 65 / 144 |
