Grindex Mega Drainage Pump (Model N & H)
The Mega pump is ideal for operation in deep excavations where very high head pumping is needed, such as in open pit mines as well as in underground mines. Other typical applications include quarries and tunnelling projects.
Mega is designed to handle pH levels from 6 to 13; zinc anodes are available for extra protection. As this pump is made of cast iron, it is also the right choice for heavy-duty applications in salt water. Grindex reliable pumps are designed for long time operation and are easy to install.
The Mega pump is available in two configurations;
Mega N (Normal head)
Mega H (High head)
Pump type
Electrical submersible 3-phase pump
Classification
Class IP 68
Max submersion
75 meters
Cable
SUBCAB
Discharge connection
4", 6" - SMS / DIN / BS / ANSI
Limitations
pH 6-13
Max liquid temp
40°C
| 60 Hz | N | H |
| Discharge connection | 6" (DN150) | 4" (DN100) |
| Rated power P2 [kW/HP] | 104 / 140 | 104 / 140 |
| Max. power consumption P1 [kW] | 110 | 110 |
| Shaft speed [r.p.m.] | 3560 | 3560 |
| Rated current at 380V | 178 A | 178 A |
| Rated current at 460V | 148 A | 148 A |
| Rated current at 575V | 118 A | 118 A |
| Solids passage [mm/inch] | 10 / 0.39 | 10 / 0.39 |
| Height [mm/inch] | 1180 / 46.5 | 1245 / 49 |
| Diameter [mm/inch] | 610 / 24 | 610 / 24 |
| Weight [kg/lbs] | 900 / 1984 | 985 / 2172 |
