Grindex Primo S8 Pump
Grindex Primo is a range of small, handy and affordable pumps, including two drainage and two sludge pumps. The Primo pumps are ideal for construction, industrial and municipal jobs, and the highly compact design allows the Primo pumps to operate in dewatering applications where others don’t fit.
Pump type
Submersible 1-phase
Classification
IP 68
Max submersion
5 m
Cable
10 m
Discharge connection
2" NPT
Limitations
pH 6.5-8
Max liquid temp
35°C
| 60 Hz | Primo S8 |
| Discharge connection | 2" |
| Rated power P2 [kW/HP] | 0.75 / 1.0 |
| Max. power consumption P1 [kW] | 1.19 |
| Shaft speed [rpm] | 3400 |
| Rated current at 115V | 10.3 A |
| Rated current at 230V | 5.1 A |
| Solids passage [mm/inch] | 25 / 1 |
| Height [mm/inch] | 416 / 16.36 |
| Diameter [mm/inch] | 241 / 9.5 |
| Weight [kg/lbs] | 13 / 29 |
